PL-NEO MPC is designed for demanding projects requiring a large number of DMX / Art-Net / sACN channels. The server offers licenses ranging from 16 to 512 universes.
Features include 24-hour Audio and Video Timeline synchronization, MIDI Time Code, PC Clock triggers, and Live Timeline Record with pixel mapping, LED matrices and video screens.
A high-performance server for large lighting projects, delivered with pre-installed software. Shows and light scenes are controlled from the internal Live Page or via mobile devices.
Features
- DMX / Art-Net / sACN control server — licenses from 16 up to 512 universes.
- 24-hour Audio, Video and Lighting timeline synchronization with MIDI Time Code.
- Live Timeline Record with pixel mapping, LED matrices and video screens.
- Wide trigger set: MIDI, RS232, DMX IN, keyboard, hyperlinks, PC clock & calendar, UDP/Ethernet (SDK).
- Pixelerr and Pixelerr PRO pre-installed; internal Live Page plus Android / iOS mobile app.
- Diecast aluminium housing with brushed anodized finish.
Specifications
| Series | DMX / Art-Net Control Server |
|---|---|
| Product code | PL-NEO MPC |
| License (NEO X) | 16, 32 or 64 universes · up to 512 universes on request |
| Protocols | DMX 512 · Art-Net · sACN — input, control and record |
| Ethernet | Yes |
| Audio / Video / Lighting timeline | Yes — 24-hour synchronization |
| Live Timeline Record | Yes — with pixel mapping, LED matrices and video screens |
| Software | Pixelerr, Pixelerr PRO — pre-installed |
| PC clock & calendar DMX modes | Yes — year, month, day, time |
| Triggers | MIDI · RS232 · DMX IN · keyboard · hyperlinks |
| UDP / Ethernet (SDK) | Yes — triggers and commands |
| DVI supported resolution (PRO) | 1024 × 768 (NEO S) · 1280 × 720 / 1280 × 1024 (NEO PRO S) |
| Mobile application | Yes — Android / iOS |
| Show control | Internal Live Page or mobile devices |
| Operating / storage humidity | 0 – 80 % RH, non-condensing |
| Protection class | IP20 |
| Power | 100 – 240 V AC, 50/60 Hz |
| Dimensions | W 430 mm × H 88.5 mm × D 400 mm |
| Weight | 3.5 kg (7.7 lb) |
| Housing | Diecast (or extruded) aluminium with brushed anodized finish |
| Operating temperature | –40 °C to +85 °C |
| Compliance / warranty | CE, RoHS · 5 years international warranty |
